| Brand Name : | RITEL or OEM |
| Certification : | CE |
| Model Number : | Central loose tube layer-stranded fiber optic cable GYTA, GYTS, GYTY for outdoor duct and non-self supporting aerial |
| Price : | $10.00~$30.00/km |
| Delivery Time : | 5~7 days |
| Payment Terms : | T/T, Paypal, Western Union |
| Supply Ability : | 1000~20000km per months |
■ Steel wire strength, filler, aluminum tape armord.
■ Good ultra violet radiation resistant property.
■ Good moisture-resistance.
| Optical Characteristics | ||||||||||
| Fiber Type | Multimode | G.651 | A1a:50/125 | Graded-index fiber | ||||||
| A1b:62.5/125 | ||||||||||
| Singlemode | G.652(A/B/C/D) | B1.1:Conventional fiber | ||||||||
| G.653 | B2: Zero dispersion shifted | |||||||||
| G.654 | B1.2 :Cut-off wavelength shifted | |||||||||
| G.655 | B4: Main technical data for positive dispersion shifted single-mode fiber | |||||||||
Cable characteristics
| Cable Count | Out sheath Diameter | Weight | Miax alloable Tensile Strength (N) | max alloable Crush Load (N/100mm) | Miin Bending Radius | Storage temperature | ||||
| (MM) | (KG) | short term | long term | short term | long term | short term | long term | (C) | ||
| 24~42 | 10.5 | 105.00 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40~+60 | |
| 48~72 | 12.0 | 150.00 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40~+60 | |
| 144 | 15.5 | 245.00 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40~+60 | |
| 288 | 21.5 | 415.00 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40~+60 | |
Different construction and material have different performance, pls. come to us for specify.
Fiber optical cable list:
DUCT/AERIAL, Non Self-supporting------GYTA, GYTS, GYTY, GYFTY, GYXTW, GYXTS
AERIAL, Figure-8 Self-supporting---------GYTC8A, GYTC8S, GYTC8Y, GYXTC8S, GYXTC8Y, ADSS
DIRECT BURIED-------------------------------GYTA53, GYFTA53, GYTY53, GYFTY53
OEM/ODM/EMS is welcome!
|
|
