    40~1050MHz GPON/EPON/GEPON fttx passive optic receiver OR100 for triple-play

    Ask Lasest Price
    Brand Name : RITEL
    Model Number : 40~1050MHz GPON/EPON/GEPON fttx passive optic receiver OR100,OR100WF,OR100WD for triple-play
    Certification : CE
    Price : $1.00~$10.00
    Payment Terms : T/T, Paypal, Western Union
    Supply Ability : 5K~10Kpcs per months
    Delivery Time : 5~7 days
    • Product Details
    • Company Profile

    40~1050MHz GPON/EPON/GEPON fttx passive optic receiver OR100 for triple-play

    40~1050MHz GPON/EPON/GEPON fttx passive optic receiver OR100,OR100WF,OR100WD for triple-play

    Features

    ■ No power required.

    ■ Original high quality fast response PD.

    ■ Built-in filter and WDM option.

    ■ Adaptor, pigtail, zinc-alloy and box available.


    Specifications

    ItemUnitParameterRemark
    Optic Parameter
    Work Wavelengthnm1260~1620ORN100
    nm1540~1563ORN100WF
    Pass Wavelengthnm1310, 1490ORN100WD
    Input Optic PowerdBm-14~ +2
    Suggested Optic PowerdBm-12~0
    Return LossdB≥55
    InterfaceSC/APCSC/PC
    Link Parameter
    C/NdB≥51
    C/CTBdB≥65
    C/CSOdB≥60
    RF Parameter
    Frequency RangeMHz40~1050
    FlatnessdB±0.75
    Output LeveldBuV68Pin=-1dBm
    Return LossdB≥14
    Output Port1F female
    ImpedanceΩ75
    General
    Dimensionmm65W*22D*10H82W*49D*22H
    WeightKg0.030.05

    Order Information

    ModelInput wavelengthCATV Operating wavelengthData PassInputOutput
    ORN1001310 or 15501260~1620SC/APC
    ORN100WF1310,1490/15501540~1563SC/APC
    ORN100WD1310/1490SC/APCSC/UPC

    OEM/ODM/EMS is welcome!
